AH285
HALL-EFFECT SMART FAN MOTOR CONTROLLER
AH285
Document number: DS31029 Rev. 8 - 2
6 of 9
www.diodes.com
June 2010
© Diodes Incorporated
Performance Characteristics
T
A
(
°C) 25 50 60 70 75 80 85 90 95 100
P
D
(mW) 800 640 576 512 480 448 416 384 352 320
T
A
(
°C) 105 110 115 120 125 130 135 140 145 150
P
D
(mW) 288 256 224 192 160 128 96 64 32 0
P ow er D issipation Curve
0
1 0 0
2 0 0
3 0 0
4 0 0
5 0 0
6 0 0
7 0 0
8 0 0
9 0 0
0 2 5 5 0 7 5 10 0 1 2 5 1 50
T
A
(°C)
P
D
(mW )
-4 0
