SIXTEEN-CHANNEL, 75mA CURRENT SINK WITH CURRENT MATCH AP3616
5
BCD Semiconductor Manufacturing Limited
Data Sheet
Jul. 2012 Rev. 1. 2
Ordering Information
Package Temperature Range Part Number Marking ID Packing Type
SOIC-28
-40 to 85 o C
AP3616M-G1 AP3616M-G1 Tube
HSOP-28 AP3616M28-G1 AP3616M28-G1 Tube
Circuit Type
Package
G1: Green
BCD Semiconductor's Pb-free products, as designated with "G1" suffix in the part number, are RoHS compliant and green.
Parameter Symbol Value Unit
Input Voltage V
IN
30 V
FLAG Pin Voltage V
FLAG
30 V
EN Pin Voltage V
EN
30 V
Voltage on Each Channel V
CHX
-0.3 to 60 V
Voltage on Other Seperate Pins -0.3 to 6 V
Thermal Resistance (Junction to
Ambient, No Heat Sink) SOIC-28
θ
JA
72 o
C/W
HSOP-28 59 o C/W
Operating Junction Temperature T
J
150 o C
Lead Temperature (Soldering, 10sec) T
STG
-65 to 150 o
C
ESD (Human Body Model) 2000 V
ESD (Machine Model) 200 V
Note 1: Stresses greater than those listed under "Absolute Maximum Ratings" may cause permanent damage to the device.
These are stress ratings only, and functional operation of the device at these or any other conditions beyond those indicated
under "Recommended Operating Conditions" is not implied. Exposure to "Absolute Maximum Ratings" for extended periods
may affect device reliability.
Absolute Maximum Ratings (Note 1)
Blank: Tube
M: SOIC-28
AP3616 -
M28:HSOP-28
