100mA REGULATED CHARGE PUMP AP3602A/B
8
Dec. 2012 Rev. 2. 0 BCD Semiconductor Manufacturing Limited
Data Sheet
Typical Performance Characteristics
Figure 4. Output Voltage vs. Output Current Figure 5. Efficiency vs. Input Voltage
Figure 6. Efficiency vs. Output Current Figure 7. V
OUT
Start UpTime, @ No Load
Typical Performance Characteristics for AP3602A
(
Unless otherwise noted, V
IN
=3.0V, C
IN
=C
OUT
=10 μ F, C
FLY
=1 μ F Ceramic Cap, T
A
=25 o
C )
0 25 50 75 100 125 150
4.0
4.2
4.4
4.6
4.8
5.0
5.2
O
utput Voltage
(V
)
Output Current (mA)
AP3602-5.0V, V
IN
=3.0V
AP3602-5.0V, V
IN
=2.7V
2.5 3.0 3.5 4.0 4.5 5.0
40
50
60
70
80
90
100
Ef
ficiency
(%)
Input Voltage (V)
AP3602-5.0V, I
OUT
=25mA
AP3602-5.0V, I
OUT
=50mA
AP3602-5.0V, I
OUT
=100mA
0.1 1 10 100
70.0
72.5
75.0
77.5
80.0
82.5
85.0
87.5
90.0
92.5
95.0
Ef
ficiency
(%)
Output Current (mA)
AP3602-5.0V, V
IN
=2.7V
AP3602-5.0V, V
IN
=3.0V
Time 40 μS/div
V
S
HDN
2V/div
V
OU
T
1V
/div
V
SHDN
0V to 3V
