Absolute Maximum Ratings
(Note 3)
Parameter Symbol Value Unit
Input Voltage V
IN
20 V
Operating Junction Temperature T
J
+150 ºC
Storage Temperature T
S
-65 to +150 ºC
Lead Temperature (Soldering, 10sec) T
LEAD
+260 ºC
Thermal Resistance (No Heatsink, Note 4) θ
JA
SOT223 120
o C/W
SOT89 165
TO220-3 60
TO252-2
(3)/TO252-2
(4)/TO252-2 (5)
100
TO263 60
ESD (Human Body Model) ESD 2000 V
ESD (Machine Model) ESD 250 V
Notes: 3. Stresses greater than those listed under "Absolute Maximum Ratings" may cause permanent damage to the device. These are stress ratings only, and
functional operation of the device at these or any other conditions beyond those indicated under "Recommended Operating Conditions" is not implied.
Exposure to "Absolute Maximum Ratings" for extended periods may affect device reliability.
4. Absolute maximum ratings indicate limits beyond which damage to the component may occur. Electrical specifications do not apply when operating the
device outside of its operating ratings. The maximum allowable power dissipation is a function of the maximum junction temperature, T J(max), the
junction-to- ambient thermal resistance, θ
JA,
and the ambient temperature, T
A.
The maximum allowable power dissipation at any ambient temperature is
calculated using: P
D(max)
= (T
J(max)
-T
A
)/θ
JA.
Exceeding the maximum allowable power dissipation will result in excessive die temperature, and the
regulator will go into thermal shutdown.
Recommended Operating Conditions
Parameter Symbol Min Max Unit
Input Voltage V
IN
– 15 V
Operating Junction Temperature Range T
J -40 +125 ºC
