AP7333
300mA, Low Quiescent Current, Fast Transient
Low Dropout Linear Regulator
AP7333 Rev. 2 4 of 12 NOVEMBER 2009
www.diodes.com © Diodes Incorporated
Absolute Maximum Ratings
Symbol Parameter Ratings Units
ESD HBM Human Body Model ESD Protection 6 kV
ESD MM Machine Model ESD Protection 400 V
V
IN
Input Voltage 7 V
Continuous Load Current Internal Limited
T
OP
Operating Junction Temperature Range -40 ~ 125 °C
T
ST
Storage Temperature Range -65 ~150 °C
P
D
Power Dissipation (Note 3)
SOT23 600 mW
SOT23R 540 mW
T
J
Maximum Junction Temperature 150 °C
Recommended Operating Conditions
Symbol Parameter Min Max Unit
V
IN
Input voltage 2 6 V
I
OUT
Output Current (Note 4) 0 300 mA
T
A
Operating Ambient Temperature -40 85
°C
Notes: 3. Ratings apply to ambient temperature at 25°C
4. The device maintains a stable, regulated output voltage without a load current.
