Typical Performance Characteristics
Start-Up Time
Time (40μs/div)
Start-Up Time
Time (40μs/div)
Line Transient Response
Time (40 μs/div)
Line Transient Response
Time (40 μs/div)
Load Transient Response
Time (100 μs/div)
Load Transient Response
Time (100 μs/div)
V
OUT
=5.0V (2V/div)
with no load
V
EN
=0 to 2V (1V/div)
V
IN
=5.5V
C
IN
=C
OUT
=1 μF
V
IN
=5.5V to 6.0V (1V/div)
Tr=Tf=2 μs
C
IN
=none, C
OUT
=1 μF
V
OUT
=5.0V (10mV/div)
I
OUT
=30mA(50mA/div)
I
OUT
=300mA(200mA/div)
V
OUT
=5.0V (10mV/div)
V
IN
=5.5V to 6.0V (1V/div)
Tr=Tf=2 μs
C
IN
=none, C
OUT
=1 μF
V
EN
=0 to 2V (1V/div)
V
IN
=5.5V
C
IN
=C
OUT
=1 μF
V
OUT
=5.0V (2V/div)
with 300mA load
V
IN
=V
EN
=5.5V
C
IN
=C
OUT
=1 μF
Tr=Tf=1 μs
V
IN
=V
EN
=5.5V
C
IN
=C
OUT
=1 μF
Tr=Tf=1 μs
V
OUT
=5.0V (100mV/div)
I
OUT
=10mA to 300mA (200mA/div)
V
OUT
=5.0V (100mV/div)
I
OUT
=10mA to 150mA (200mA/div)
