Diodes AP7217D - Manual

AP7217D
1.2V 600mA CMOS LDO
AP7217D Rev. 2 1 of 9 FEBRUARY 2009
www.diodes.com © Diodes Incorporated
•
Low Current Consumption: Typ. 40 μA
• Output Voltage: 1.2V
• Guaranteed 600mA Output Current
•
Dropout Voltage 850mV at 600mA Output Current
•
Input Voltage Range: 2.5V to 5.5V
• Current Limit Protection
• Thermal shutdown Protection
•
Stability with Low ESR Capacitors
• Low Temperature Coefficient
• SOT89-3L: Available in “Green” Molding Compound
(No Br, Sb)
• Lead Free Finish/ RoHS Compliant (Note 1)
The AP7217D low-dropout linear regulator operates from 2.5V to
5.5V supply and delivers a guaranteed 600mA continuous load
current.
The space-saving SOT89-3L package is suitable for “pocket” and
hand-held application.
• CD and MP3 Players
• Cellular and PCS Phones
• Digital Still Camera
• Hand-Held
Computers
AP 7217D - 12 Y G - 13
Output voltage Package
12 : 1.2V
Packing Green
G : Green 13 : Tape & Reel Y : SOT89-3L
Device
Package
Code
Packaging
(Note 2)
13” Tape and Reel
Quantity Part Number Suffix
AP7217D-12YG-13 Y SOT89-3L 2500/Tape & Reel -13
Notes: 1. EU Directive 2002/95/EC (RoHS). All applicable RoHS exemptions applied. Please visit our website at
http://www.diodes.com/products/lead_free.html .
2. Pad layout as shown on Diodes Inc. suggested pad layout document AP02001, which can be found on our website at
http://www.diodes.com/datasheets/ap02001.pdf .
Features General Description
Applications
Ordering Information
