600mA LOW DROPOUT LINEAR REGULATOR AP1117M
Data Sheet
600mA LOW DROPOUT LINEAR REGULATOR AP2317
10
Mar. 2007 Rev. 1. 6 BCD Semiconductor Manufacturing Limited
Typical Applications
Figure 16. Typical Applications of AP2317
AP2317-ADJ
V
IN
V
OUT
ADJ
V
IN
=11V
10 µF
R1
160
Ω
R2
1k Ω
22
µF
9V at 0.6A
+ +
+ +
V
IN
=5.3V AP2317-3.3
V
IN
V
OUT
GND
10
µF
22
µF
3.3V at 0.6A
V
OUT
=V
REF
* ( 1+R2/R1) + I
ADJ
* R2
