150mA RF ULDO REGULATOR AP2202
Data Sheet
10
Jul. 2011 Rev. 2. 2
BCD Semiconductor Manufacturing Limited
Parameter
Symbol
Conditions
Min
Typ
Max
Unit
Output Voltage Accuracy
∆V
OUT
/V
OUT
Variation from specified
V
OUT
-1
1
%
-2
2
Output Voltage
Temperature Coefficient
(Note 3)
∆V
OUT
/
∆T
120
µV/
o
C
(∆V
OUT
/V
OUT
)/
∆T
46
ppm/
o
C
Line Regulation
V
RLINE
V
IN
=3.6V to 13.2V
1
3
mV
13
Load Regulation
(Note 4)
V
RLOAD
I
OUT
=0.1mA to 150mA
1
6
mV
14
Dropout Voltage (Note 5)
V
DROP
I
OUT
=100
µA
15
50
mV
70
I
OUT
=50mA
110
150
230
I
OUT
=100mA
140
250
300
I
OUT
=150mA
165
275
350
Standby Current
I
STD
V
EN
≤0.4V (shutdown)
0.01
1
µA
V
EN
≤0.18V (shutdown)
5
Ground Pin Current
(Note 6)
I
GND
V
EN
≥2.0V, I
OUT
=0
µA
95
130
µA
150
V
EN
≥2.0V, I
OUT
=100
µA
98
140
160
V
EN
≥2.0V, I
OUT
=50mA
350
600
800
V
EN
≥2.0V, I
OUT
=100mA
600
1000
1500
V
EN
≥2.0V, I
OUT
=150mA
1300
1900
2500
Ripple Rejection
PSRR
frequency=100Hz, I
OUT
=100
µA
75
dB
Current Limit
I
LIMIT
V
OUT
=0V
320
550
mA
Output Noise
e
no
I
OUT
=50mA, C
OUT
=2.2
µF,
100pF from BYP to GND
260
Enable Input Logic-Low
Voltage
V
IL
Regulator shutdown
0.4
V
0.18
Hz
nV /
AP2202-2.6 Electrical Characteristics
Electrical Characteristics (Continued)
V
IN
=3.6V, I
OUT
=100
µA, C
IN
=1.0
µF, C
OUT
=2.2
µF, V
EN
≥2.0V, T
J
=25
o
C, Bold typeface applies over -40
o
C
≤T
J
≤125
o
C (note 2),
unless otherwise specified.
