300mA HIGH SPEED, EXTREMELY LOW NOISE CMOS LDO REGULATOR AP2128
Data Sheet
19
Sept. 2010 Rev. 2.0 BCD Semiconductor Manufacturing Limited
Typical Application
V
OUT
=0.8(1+R1/R2) V
V
OUT
=1.0V to 5.2V
Figure 40. Typical Application of AP2128
V
IN
V
IN
V
OUT
V
OUT
Shutdown
GND
C
OUT
1 µF
C
IN
1 µF
AP2128
V
IN
V
IN
V
OUT
V
OUT
ADJ Shutdown
GND
C
OUT
1 µF
C
IN
1 µF
R1
R2
AP2128
