300mA HIGH SPEED, EXTREMELY LOW NOISE CMOS LDO REGULATOR AP2129
Data Sheet
14
Sep. 2012 Rev. 1. 6 BCD Semiconductor Manufacturing Limited
Mechanical Dimensions
DFN-1.5x2-6 Unit: mm(inch)
1.424(0.056)
1.576(0.062)
1.
9
24(
0.
07
6)
2.
0
76(
0.
08
2)
0.500(0.020)
TYP.
0.200(0.008)
MIN.
0.174(0.007)
0.326(0.013)
0.
8
00
(0.
03
1)
1.
0
00
(0.
03
9)
1.000(0. 039)
1.200(0. 047)
0.200(0. 008)
0.300(0. 012)
Pin 1 Mark
0.350(0.014)
0.450(0.018)
0. 127(0.005)
REF
0.000(0. 000)
0.050(0. 002)
N1 N3
N4 N6
1
DETAIL A
Pin 1 options
2
PIN #1 IDENTIFICATION
See DETAIL A
1 2 1 2
