300mA HIGH SPEED, EXTREMELY LOW NOISE CMOS LDO REGULATOR AP2126
4
Sep. 2012 Rev. 1. 5
BCD Semiconductor Manufacturing Limited
Data Sheet
Parameter
Symbol
Value
Unit
Input Voltage
V
IN
6.5
V
Shutdown Input Voltage
V
CE
-0.3 to V
IN
+0.3
V
Output Current
I
OUT
450
mA
Junction Temperature
T
J
150
o
C
Storage Temperature Range
T
STG
-65 to 150
o
C
Lead Temperature (Soldering, 10sec)
T
LEAD
260
o
C
Thermal Resistance (Junction to Ambient)
θ
JA
250
o
C/W
ESD (Human Body Model)
ESD
6000
V
ESD (Machine Model)
ESD
250
V
Absolute Maximum Ratings (Note 1)
Parameter
Symbol
Min
Max
Unit
Input Voltage
V
IN
3.0
6
V
Operating Ambient Temperature Range
T
A
-40
85
o
C
Recommended Operating Conditions
Note 1: Stresses greater than those listed under "Absolute Maximum Ratings" may cause permanent damage to the device.
These are stress ratings only, and functional operation of the device at these or any other conditions beyond those indicated
under "Recommended Operating Conditions" is not implied. Exposure to "Absolute Maximum Ratings" for extended periods
may affect device reliability.
