AP1086
1.5A LOW DROPOUT POSITIVE ADJUSTABLE OR
FIXED-MODE REGULATOR
AP1086
Document number: DS31028 Rev. 6 - 2
6 of 10
www.diodes.com
June 2010
© Diodes Incorporated
Ordering Information
AP1086 X XX X - X
Low Dropout Regulator Package Vout
K : TO263-3L
D : TO252-3L
T : TO220-3L
Blank = Adj
15 = 1.5V
18 = 1.8V
25 = 2.5V
33 = 3.3V
50 = 5.0V
Packing
U : Tube
13 : Taping & Reel
Lead Free
G : Green
L : Lead Free
Device
Package
Code
Packaging
(Note 5)
Tube 13” Tape and Reel
Quantity
Part Number
Suffix
Quantity
Part Number
Suffix
AP1086DXXL-13 D TO252-3L NA NA 2500/Tape & Reel -13
AP1086DXXG-13 D TO252-3L NA NA 2500/Tape & Reel -13
AP1086KXXL-13 K TO263-3L NA NA 800/Tape & Reel -13
AP1086KXXG-13 K TO263-3L NA NA 800/Tape & Reel -13
AP1086TXXL-U T TO220-3L 50 -U NA NA
AP1086TXXG-U T TO220-3L 50 -U NA NA
Notes: 5. Pad layout as shown on Diodes Inc. suggested pad layout document AP02001, which can be found on our website at
http://www.diodes.com/datasheets/ap02001.pdf.
