Advance Datasheet
1.0A High-side Power Distribution Switch with Enable and Flag AP2810
Jul. 2012 Rev 1. 2 BCD Semiconductor Manufacturing Limited
10
Typical Performance Characteristics (Continued)
Time(2ms/div) Time(100ms/div)
Figure 16. Output Turn OFF and Falling Time Figure 17. Output Short to GND Current
(V
IN
=5V, C
IN
=1.0μF, C
OUT
=470μF, R
L
=5.0Ω) (V
IN
=5V,C
IN
=1.0μF)
Time(5ms/div) Time(5ms/div)
Figure 18. FLAG Response During Over Current Figure 19. FLAG Response During Over Temperature
(V
IN
=5V, C
IN
=1.0μF, C
OUT
=470μF) (V
IN
=5V, C
IN
=1.0μF, C
OUT
=220μF, R
L
=5.0Ω)
V
EN
(5V/div)
V
OUT
(1V/div)
I
OUT
(1A/div)
V
EN
(5V/div)
V
OUT
(1V/div)
I
OUT
(1A/div)
V
FLAG
(1V/div)
V
OUT
(1V/div)
I
OUT
(1A/div)
V
FLAG
(1V/div)
V
OUT
(1V/div)
I
OUT
(1A/div)
