APM8601
DUAL CHANNEL SINGLE CELL LINEAR LITHIUM BATTERY
CHARGER WITH 28V OVP and PROGRAMMABLE CHARGE
TIMER
APM8601
Document number: DS35138 Rev. 1 - 2
4 of 14
December 2010
© Diodes Incorporated
NEW PROD
UC
T
Absolute Maximum Ratings
Symbol
Parameter
Rating
Unit
DC, USB to GND
-0.3 to 28V
V
BAT, CT, SETI, USEL, THM,
FLT
,
CHG
,
POK
,
EN
to GND
-0.3 to 6V
V
ESD Susceptibility (Note 2)
HBM Human
Body
Model
2
kV
MM Machine
Model
200
V
Note:
2. Semiconductor devices are ESD sensitive and may be damaged by exposure to ESD events. Suitable ESD precautions should be
taken when handling and transporting this device.
Thermal Resistance
(Note 3)
Symbol
Parameter
Rating
Unit
θ
JA
Junction to Ambient
40
°C/W
Note:
3. Test condition for DFN3030-10: Device mounted on FR-4 2-layer board, 2oz copper, with minimum recommended pad on top layer and 6 vias to
bottom layer 1.0”x1.5” ground plane.
Recommended Operating Conditions
(Note 4)
Symbol
Parameter
Rating
Unit
Ambient Temperature Range
-40 to +85
°C
Input Supply Voltage
4.15 to 7.00
V
I
CHARGE
Typical Charge Current
0.1 to 1.0
A
Note:
4. The device function is not guaranteed outside of the recommended operating conditions.
