AP3513E
Document number: DS36692 Rev.
2 - 2
3 of 11
January 2014
© Diodes Incorporated
AP3513E
A Product Line of
Diodes Incorporated
N
E
W
P
R
O
D
U
C
T
Absolute Maximum Ratings
(Note 4)
Symbol
Parameter
Rating
Unit
V
IN
IN Pin Voltage
-0.3 to 20
V
V
EN
EN Pin Voltage
-0.3 to V
IN
V
V
SW
SW Pin Voltage
21
V
V
BS
BS Pin Voltage
-0.3 to V
SW
+6
V
V
FB
FB Pin Voltage
-0.3 to 6
V
V
COMP
COMP Pin Voltage
-0.3 to 6
V
V
SS
SS Pin Voltage
-0.3 to 6
V
T
J
Operating Junction Temperature
+150
ºC
T
STG
Storage Temperature
-65 to +150
ºC
T
LEAD
Lead Temperature (Soldering, 10sec)
+260
ºC
θ
JA
Thermal Resistance (Junction to Ambient)
SO-8EP
60
o
C/W
V
HBM
ESD (Human Body Model)
2000
V
V
MM
ESD (Machine Model)
200
V
Note 4:
Stresses greater than those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and
functional operation of the device at these or any other conditions beyond those indicated under “Recommended Operating Conditions” is not implied.
Exposure to “Absolute Maximum Ratings” for extended periods may affect device reliability.
Recommended Operating Conditions
Symbol
Parameter
Min
Max
Unit
V
IN
Input Voltage
4.5
18
V
T
A
Operating Ambient Temperature
-40
+85
ºC
