AP5002
PWM CONTROL 2A STEP-DOWN CONVERTER
AP5002 Rev. 8
1 of 10
FEBRUARY 2009
©
Diodes Incorporated
•
Input voltage: 3.6V to 20V
•
Output voltage: 0.8V to V
CC
•
Duty ratio: up to 100% PWM control
•
Oscillation frequency: 500KHz typical
•
Soft-start Current Limit, Enable function
• Thermal
Shutdown
function
•
Built-in internal SW P-channel MOS
•
Low ESR output capacitor (MLCC, multi-layer ceramic
capacitor) support
• Efficiency
90%
•
SOP-8L: Available in “Green” Molding Compound
(No Br, Sb)
•
Lead Free Finish / RoHS Compliant (Note 1)
AP5002 consists of step-down switching regulator with
PWM control. These devices include a reference voltage source,
oscillation circuit, error amplifier, internal PMOS.
AP5002 provides low-ripple power, high efficiency, and excellent
transient characteristics. The PWM control circuit is able to vary
the duty ratio linearly up to 100%. This converter also contains
an error amplifier circuit as well as a soft-start circuit that prevents
overshoot at startup. An enable function, an over current protect
function and a short circuit protect function are built inside, and
when OCP or SCP happens, the operation frequency will be
reduced from 500KHz to 50KHz. Also, an internal compensation
block is built in to minimum external component count.
With the addition of an internal P-channel Power MOS, a coil,
capacitors, and a diode connected externally, these ICs can
function as step-down switching regulators. They serve as ideal
power supply units for portable devices when coupled with the
SOP–8L mini-package, providing such outstanding features as
low current consumption. Since this converter can accommodate
an input voltage up to 22V, it is also suitable for the operation via
an AC adapter.
• PC
Motherboard
• LCD
Monitor
• Graphic
Card
• DVD-Video
Player
• Telecom
Equipment
• ADSL
Modem
•
Printer and other Peripheral Equipment
• Microprocessor
core
supply
•
Networking power supply
AP5002 S G - 13
Package
Packing
S : SOP-8L
13 : Tape & Reel
Green
G : Green
Device
Package
Code
Packaging
(Note 2)
13” Tape and Reel
Quantity
Part Number Suffix
AP5002SG-13 S
SOP-8L
2500/Tape
&
Reel
-13
Notes: 1. EU Directive 2002/95/EC (RoHS). All applicable RoHS exemptions applied. Please visit our website at
2. Pad layout as shown on Diodes Inc. suggested pad layout document AP02001, which can be found on our website at
Features
General Description
Applications
Ordering Information
