Data Sheet
1.2A, 1.4MHz High Efficiency Synchronous DC-DC Buck Converter AP3407/A
Dec. 2011 Rev. 1. 3 BCD Semiconductor Manufacturing Limited
10
Mechanical Dimensions
SOT-23-5 Unit: mm(inch)
2.820(0.111)
0.000(0.000)
0.300(0.012)
0.950(0.037)
0.900(0.035)
0.100(0.004)
0.200(0.008)
8°
0°
3.020(0.119)
0.400(0.016)
0.150(0.006)
1.300(0.051)
0.200(0.008)
1.800(0.071)
2.000(0.079)
0.700(0.028)
REF
TYP
