AP1538
18V 3A 300KHz BUCK CONVERTER
AP1538 Rev. 5
4 of 13
OCTOBER 2009
DS31451
©
Diodes Incorporated
Absolute Maximum Ratings
Symbol
Parameter
Rating
Unit
ESD HBM Human Body Model ESD Protection
5.5
KV
ESD MM
Machine Model ESD Protection
200
V
V
CC
V
CC
Pin Voltage
V
SS
- 0.3 to V
SS
+ 20
V
V
FB
Feedback Pin Voltage
V
SS
- 0.3 to V
CC
V
V
EN
EN Pin Voltage
V
SS
- 0.3 to V
CC
V
V
OUT
Switch
Pin
Voltage
V
SS
- 0.3 to V
CC
V
P
D
Power Dissipation
Internally limited
mW
T
J
Operating Junction Temperature Range
-40 to +125
o
C
T
ST
Storage Temperature Range
-65 to +150
o
C
Caution: The absolute maximum ratings are rated values exceeding which the product could suffer physical damage.
These values must therefore not be exceeded under any conditions.
Recommended Operating Conditions
Symbol
Parameter
Min
Max
Unit
V
IN
Input Voltage (Note 4)
3.6
18
V
I
OUT
Output
Current
0
3
A
T
A
Operating Ambient Temperature
-20
+85
o
C
Notes: 4. For the operations in low input voltage, AP1538 can tolerate down to 3.6V but max output current loading will be less than 3A. For nominal
applications in such low input voltage range, especially lower than 4V, a higher ROCSET with larger heat sink is recommended.
