AP1507
150KHz, 3A PWM BUCK DC/DC CONVERTER
AP1507
Document number: DS31067 Rev. 3 - 2
10 of 12
www.diodes.com
May 2012
© Diodes Incorporated
Ordering Information
Package
D5 : TO252-5L
Output Version
AP1507 - XX XX X X
Packing
-U : Tube
-13 : Tape & Reel
Blank : Adjustable
33 : 3.3V
50 : 5.0V
12 : 12V
Lead Free
L : Lead Free
Blank : Green
Device Package Code
Packaging
(Note 5)
Tube/Bulk 13” Tape and Reel
Quantity
Part Number
Suffix
Quantity Part Number Suffix
AP1507-XXD5L-XX D5 TO252-5L 80 -U 2500/Tape & Reel -13
AP1507-XXD5-XX D5 TO252-5L Not available 2500/Tape & Reel -13
Note: 5. Pad layout as shown on Diodes Inc. suggested pad layout document AP02001, which can be found on our website at
http://www.diodes.com/datasheets/ap02001.pdf
Marking Information
(1) TO252-5L
1507 - XX Output Type :
Blank : Adjustable
1507-50 : 5.0V
1507-12 : 12V
Logo
Internal code
Xth Week : 01~52
Year :
( Top view )
"08" = 2008
"07" = 2007
YY WW X X
L : Lead Free
Blank : Green
1507-33 : 3.3V
Pb
Lead-Free
