AP1501A
150KHz, 5A PWM BUCK DC/DC CONVERTER
AP1501A Rev. 10 5 of 14 SEPTEMBER 2009
DS31191 www.diodes.com © Diodes Incorporated
Absolute Maximum Ratings
Symbol Parameter Rating Unit
ESD MM Machine Model ESD Protection 400 V
V
CC
Supply Voltage +45 V
V
SD
ON/OFF Pin input voltage -0.3 to +40 V
V
FB
Feedback Pin voltage -0.3 to +40 V
V
OUT
Output voltage to Ground -1 V
P
D
Power dissipation Internally limited W
T
ST
Storage temperature -65 to +150
o
C
T
J
Operating Junction Temperature -20 to +125 o C
Recommended Operating Conditions
Symbol Parameter Rating Units
V
OP
Operating voltage 4.5 to 40 V
T
A
Operating Ambient Temperature -20 to 85 o C
