1.5A STEP-DOWN/STEP-UP/INVERTING DC-DC CONVERTER AZ34063U
5
Jan. 2013 Rev. 1. 3
BCD Semiconductor Manufacturing Limited
Data Sheet
(
V
CC
=5.0V, T
A
=-40 to 85
o
C, unless otherwise specified.)
Note 3: Low duty cycle pulse technique are used during test to maintain junction temperature as close to ambient temperature
as possible.
Note 4: If the output switch is driven into hard saturation (non-Darlington configuration) at low switch currents (
≤300mA) and
high driver currents (
≥30mA), it may take up to 2.0μs for it to come out of saturation. This condition will shorten the off time
at frequencies 30KHz, and is magnified at high temperatures. This condition does not occur with a Darlington configuration,
since the output switch cannot saturate. If a non-Darlington configuration is used, the following output drive condition is rec-
ommended:
Parameter
Symbol
Conditions
Min
Typ
Max
Unit
OSCILLATOR
Frequency
f
OSC
V
PIN5
=0V, C
T
=1.0nF
T
A
=25
o
C
30
38
45
KHz
Charge Current
I
CHG
V
CC
=5.0V to 36V, T
A
=25
o
C
30
38
45
μA
Discharge Current
I
DISCHG
V
CC
=5.0V to 36V, T
A
=25
o
C
180
240
290
μA
Discharge to Charge Current
Ratio
I
DISCHG
/I
CHG
Pin 7 to V
CC
, T
A
=25
o
C
5.2
6.5
7.5
Current Limit Sense Voltage
V
IPK
(sense) I
CHG
=I
DISCHG
, T
A
=25
o
C
250
300
350
mV
OUTPUT SWITCH (Note 3)
Saturation Voltage,
Dalington Connection
V
CE
(sat)
I
SW
=1.0A, Pins 1, 8 connected,
Common Emitter
1.0
1.3
V
Saturation Voltage (Note 4.)
V
CE
(sat)
I
SW
=1.0A, R
PIN8
=82
Ω to V
CC
,
Forced
β=20, Common Emitter
0.45
0.7
V
DC Current Gain
h
FE
I
SW
=1.0A, V
CE
=5.0V,
T
A
=25
o
C
50
75
Collector Off-State Current
I
C
(off)
V
CE
=36V
0.01
100
μA
COMPARATOR
Threshold Voltage
V
TH
T
A
=25
o
C
1.225 1.250 1.275
V
T
A
=-40 to 85
o
C
1.21
1.250
1.29
Threshold Voltage Line
Regulation
R
EGLINE
V
CC
=3.0V to 36V
1.4
5
mV
Input Bias Current
I
IB
V
IN
=0V
-20
-400
nA
TOTAL DEVICE
Supply Current
I
CC
V
CC
=5.0V to 36V, C
T
=1.0nF,
V
PIN7
=V
CC
, V
PIN5
>V
TH
,
V
PIN2
=GND, other pins open
4
mA
