D5V0F4U6SO
Document number: DS35472 Rev. 4 - 2
2 of 4
July 2013
© Diodes Incorporated
D5V0F4U6SO
NEW PROD
UC
T
Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol
Value
Unit
Conditions
Peak Pulse Current
I
PP
3.0 A
8/20µs, Per Figure 3
ESD Protection – Contact Discharge
V
ESD_Contact
±8 kV
Standard IEC 61000-4-2
ESD Protection – Air Discharge
V
ESD_Air
±15 kV
Standard IEC 61000-4-2
Thermal Characteristics
Characteristic Symbol
Value
Unit
Power Dissipation (Note 5)
P
D
300
mW
Thermal Resistance, Junction to Ambient (Note 5)
R
θJA
417 °C/W
Operating and Storage Temperature Range
T
J
, T
STG
-65 to +150
°C
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic
Symbol
Min
Typ
Max
Unit
Test Conditions
Reverse Working Voltage
V
RWM
—
—
5.5
V
—
Reverse Current (Note 6)
I
R
— — 200 nA
V
R
= 5.5V
Reverse Breakdown Voltage
V
BR
6.0 — — V
I
R
= 1mA
Reverse Clamping Voltage, Positive Transients
(Note 7)
V
CL
— 10 12 V
I
PP
= 1A, t
p
= 8/20μs
Dynamic Resistance
R
DYN
— 1.0 — Ω
I
R
= 1A, t
p
= 8/20μs
Capacitance (Note 8)
C
T
— 0.4 0.65 pF
V
R
= 2.5V, f = 1MHz
— 0.5 — pF
V
R
= 0V, f = 1MHz
Notes:
5. Device mounted on FR-4 PCB pad layout (2oz copper) as shown on Diodes, Inc. suggested pad layout AP02001, which can be found on our website at
6. Short duration pulse test used to minimize self-heating effect.
7. Clamping voltage value is based on an 8x20µs peak pulse current (I
PP
) waveform.
8. Measured from any CH to GND.
9. For information on the impact of Diodes' USB 2.0 compatible ESD protectors on signal integrity including eye diagram plots, please refer to AN77 at the
followi
0
125
175
250
50
100
0
T , AMBIENT TEMPERATURE ( C)
Figure 1 Power Derating Curve
A
°
P
, P
O
WE
R
D
ISSI
P
A
T
IO
N (
m
W
)
D
25
100
50
75
150
200
Note 5
150
300
0
125
175
50
100
0
T , AMBIENT TEMPERATURE ( C)
Figure 2 Pulse Derating Curve
A
°
P
EA
K
P
U
LS
E
D
E
R
A
T
IN
G
%
O
F
PEAK
PO
W
E
R O
R
CUR
RENT
25
100
50
75
150
25
75
200
