D3V3F4U6S
Document number: DS35999 Rev. 3 - 2
2 of 4
June 2013
© Diodes Incorporated
D3V3F4U6S
NEW PROD
UC
T
Maximum Ratings
(@T
A
= +25°C unless otherwise specified.)
Characteristic Symbol
Value
Unit
Conditions
Peak Pulse Current
I
PP
5
A
8/20µs, Per Figure 3
ESD Protection – Contact Discharge
V
ESD_Contact
±8 kV
Standard
IEC
61000-4-2
ESD Protection – Air Discharge
V
ESD_Air
±15 kV
Standard
IEC
61000-4-2
Thermal Characteristics
Characteristic Symbol
Value
Unit
Power Dissipation (Note 5)
P
D
200 mW
Thermal Resistance, Junction to Ambient (Note 5)
R
θJA
625 °C/W
Operating and Storage Temperature Range
T
J
, T
STG
-55 to +150
°C
Electrical Characteristics
(@T
A
= +25°C unless otherwise specified.)
Characteristic
Symbol
Min
Typ
Max
Unit
Test Conditions
Reverse Working Voltage
V
RWM
—
—
3.3
V
—
Reverse Current (Note 6, 7)
I
R
—
—
200 nA
V
R
= 3.3V
Reverse Breakdown Voltage
V
BR
6.0 — — V
I
R
= 1mA
Forward Voltage
V
F
0.6 0.8 0.95 V
I
F
= 8mA
Reverse Clamping Voltage, Positive Transients
V
CL1
—
10.0
—
V
I
PP
= 1A, t
p
= 8/20μs
Reverse Clamping Voltage, Negative Transients
V
CL2
— -1.7 — V
I
PP
= -1A, t
p
= 8/20μs
Dynamic Resistance
R
DYN
—
0.9
—
I
R
= 1A, t
p
= 8/20μs
Capacitance
C
T
—
0.85 1.2 pF
V
R
= 1.65V, f = 1MHz
Notes:
5. Device mounted on FR-4 PCB pad layout (2oz copper) as shown on Diodes, Inc. suggested pad layout AP02001, which can be found on our website at
6. Short duration pulse test used to minimize self-heating effect.
7. Measured from pin 1, 3, 4, 5 or 6 to pin 2.
8. For information on the impact of Diodes' USB 2.0 compatible ESD protectors on signal integrity including eye diagram plots, please refer to AN77 at the
followi
0
125
175
150
50
100
0
T , AMBIENT TEMPERATURE ( C)
Figure 1 Power Derating Curve
A
°
P
,
P
O
WE
R
DIS
S
IP
A
T
IO
N (
m
W
)
D
25
100
50
75
150
25
75
125
200
175
Note 5
0
50
25
50
75
100 125
150
P
E
A
K
P
U
L
SE
D
E
R
A
T
IN
G
%
O
F
P
EAK
PO
W
E
R O
R
CUR
RENT
T , AMBIENT TEMPERATURE (°C)
Figure 2 Pulse Derating Curve
A
0
100
25
75
175 200
