Page 2
D1213A-04S
Document number: DS35600 Rev. 8 - 2
2 of 5
October 2012
© Diodes Incorporated
D1213A-04S
NEW PROD
UC
T
Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol Value Unit Conditions
Operating Supply Voltage
V
P
- V
N
6.0 V
-
DC Voltage at any Channel Input
-
(V
N
– 0.5) to (V
P
+ 0.5)
V
-
Peak Pulse Current
I
PP
5.0 A
8/20µs, Per Figure 3
ESD Protection – Contact Discharge
V
ESD_Contact
±8 kV
IEC 61000-4-2 Standard
ESD Protection – Air Discharge
V
ESD_Air
±15 kV
IEC 61000-4-2 Standard
Thermal Characteristics
Characteristic Symbol
Value
Unit
Power Dissipation (Note 5)
P
D
200 mW
Thermal Resistance, Junction to Ambient (Note 5)
R
θJA
625
°C/W
Operating and Storage Temperature Range
T
J
, T
STG
-55 to +150
°C
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic
Symbol
Min
Typ
Max
Unit
Test Conditions
Operating Supply Voltage
V
P
-
3.3 5.5 V
−
Operating Supply Current (Note 6)
I
P
- -
8.0
μA
(V
P
– V
N
) = 3.3V
Channel Leakage Current (Note 6)
I
R
- 0.1
1.0
μA
V
P
= 5V, V
N
= 0V
Reverse breakdown voltage
V
BR
6.0 - - V
I
R
= 1mA
Clamping Voltage, Positive Transients
V
CL1
-
10.0 - V
I
PP
= 1A (Note 7)
Clamping Voltage, Negative Transients
V
CL2
- -1.7 - V
I
PP
= -1A (Note 7)
Forward Voltage for Top Diode
V
FD1
0.60 0.80 0.95 V
I
F
= 8mA, any channel to V
P
Forward Voltage for Bottom Diode
V
FD2
0.60 0.80 0.95 V
I
F
= 8mA, V
N
to and channel
Dynamic Resistance
R
DYN
- 0.9 -
Ω
I
PP
= 1A (Note 7)
Channel Input Capacitance
C
T
- 0.85
1.2 pF
V
IN
= 1.65V, V
P
= 3.3V,
V
N
= 0V, f = 1MHz
Notes:
5. Device mounted on FR-4 PCB pad layout (2oz copper) as shown on Diodes, Inc. suggested pad layout AP02001, which can be found on our website at
6. Short duration pulse test used to minimize self-heating effect.
7. Clamping voltage value is based on an 8x20
μs peak pulse current (I
pp
) waveform.
8. Measured from any channel to V
N.
9. Measured from V
P
to V
N
.
10. For information on the impact of Diodes' USB 2.0 compatible ESD protectors on signal integrity including eye diagram plots, please refer to AN77 at the
follow
