D1213A-02SOL
Document number: DS35607 Rev. 6 - 2
3 of 4
www.diodes.com
October 2012
© Diodes Incorporated
D1213A-02SOL
NEW PROD
UC
T
0
t, TIME ( s)
Figure 3 Pulse Waveform
μ
20 40 60
100
50
0
I
, PE
AK P
U
L
S
E
CURRENT
(
%
I
)
Pp
p
P
0.01
0.4 0.6 0.8 1.0 1.2 1.4 1.6 1.8
0.1
1
10
100
1,000
I,
I
N
S
T
A
N
T
A
N
E
O
U
S
F
O
R
WA
R
D
C
U
R
R
E
N
T
(mA
)
F
Figure 4 Typical Forward Characteristics
V , INSTANTANEOUS FORWARD VOLTAGE (V)
F
T = 25°C
A
T = 85°C
A
T = 125°C
A
T = 150°C
A
T = -55°C
A
Note 7
0.01
0 1 2 3 4 5
I
, INS
T
AN
T
ANE
O
U
S
R
EVE
R
SE
C
U
R
R
EN
T
(n
A
)
R
Figure 5 Typical Reverse Characteristics
V , INSTANTANEOUS REVERSE VOLTAGE (V)
R
0.1
1
10
100
1,000
T = 25°C
A
T = 85°C
A
T = 125°C
A
T = 150°C
A
T = -55°C
A
Note 7
0.5
1.5
2.0
1.0
0
0 0.3 0.6 0.9 1.2 1.5 1.8 2.1 2.4 2.7 3.0 3.3
Figure 6 Total Capacitance vs. Reverse Voltage
V , DC REVERSE VOLTAGE (V)
R
C
, T
O
T
A
L
CA
P
A
CIT
A
NCE
(p
F
)
T
Note 7
Package Outline Dimensions
Please see AP02002 at http://www.diodes.com/datasheets/ap02002.pdf for latest version.
SOT23
Dim Min Max Typ
A 0.37 0.51 0.40
B 1.20 1.40 1.30
C 2.30 2.50 2.40
D 0.89 1.03 0.915
F 0.45 0.60 0.535
G 1.78 2.05 1.83
H 2.80 3.00 2.90
J 0.013 0.10 0.05
K 0.903 1.10 1.00
K1 - - 0.400
L 0.45 0.61 0.55
M 0.085 0.18 0.11
α 0° 8° -
All Dimensions in mm
A
M
J L
D
F
B C
H
K
G
K1
