D1213A-01LP4
Document number: DS35760 Rev. 5 - 2
2 of 4
August 2012
© Diodes Incorporated
D1213A-01LP4
NEW PROD
UC
T
Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol
Value
Unit
Conditions
Peak Pulse Current
I
PP
5 A
8/20
μs, Per Figure 2
ESD Protection – Contact Discharge
V
ESD_Contact
±8 kV
Standard IEC 61000-4-2
ESD Protection – Air Discharge
V
ESD_Air
±15 kV
Standard IEC 61000-4-2
Thermal Characteristics
Characteristic Symbol
Value
Unit
Package Power Dissipation (Note 5)
P
D
250 mW
Thermal Resistance, Junction to Ambient (Note 5)
R
θJA
500
°C/W
Operating and Storage Temperature Range
T
J
, T
STG
-65 to +150
°C
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol
Min
Typ
Max
Unit
Test
Conditions
Reverse working voltage
V
RWM
—
—
3.3
V
—
Reverse current (Note 6)
I
R
— 0.1 1.0
μA
V
R
= V
RWM
= 3.3V
Reverse breakdown voltage
V
BR
6.0 —
—
V I
R
= 1mA
Forward voltage
V
F
0.6 0.8 0.95
V I
F
= 8mA
Reverse clamping voltage, Positive Transients
V
CL1
— 10.0 —
V I
PP
= 1A, t
p
= 8/20
μs
Reverse clamping voltage, Negative Transients
V
CL2
— -1.7 —
V I
PP
= -1A, t
p
= 8/20
μs
Dynamic resistance
R
DYN
— 0.9 —
Ω
I
R
= 1A, t
p
= 8/20
μs
Capacitance
C
T
— 0.85 1.2
pF V
R
= 1.65V, f = 1MHz
