2N7002W
Document number: DS30099 Rev. 14 - 2
2 of 4
September 2013
© Diodes Incorporated
2N7002W
Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
Characteristic
Symbol
Value
Unit
Drain-Source Voltage
V
DSS
60
V
Drain-Gate Voltage R
GS
1.0M
V
DGR
60
V
Gain-Source Voltage Continuous
Pulsed
V
GSS
20
40
V
Drain Current (Note 5) Continuous
Continuous @ +100
C
Pulsed
I
D
115
73
800
mA
Thermal Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic
Symbol
Value
Unit
Total Power Dissipation (Note 5)
Derating above T
A
= +25°C
P
D
200
1.60
mW
mW
Thermal Resistance, Junction to Ambient
R
JA
625
C/W
Operating and Storage Temperature Range
T
J
, T
STG
-55 to +150
C
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic
Symbol
Min
Typ
Max
Unit
Test Condition
OFF CHARACTERISTICS (Note 6)
Drain-Source Breakdown Voltage
BV
DSS
60 70
V
V
GS
= 0V, I
D
= 10
A
Zero Gate Voltage Drain Current
@ T
C
= +25°C
@ T
C
= +125°C
I
DSS
1.0
500
A
V
DS
= 60V, V
GS
= 0V
Gate-Body Leakage
I
GSS
10
nA
V
GS
=
20V, V
DS
= 0V
ON CHARACTERISTICS (Note 6)
Gate Threshold Voltage
V
GS(th)
1.0
2.0
V
V
DS
= V
GS
, I
D
= 250
A
Static Drain-Source On-Resistance @ T
J
= +25°C
@ T
j
= +125°C
R
DS(ON)
1.8
2.6
7.5
13.5
Ω
V
GS
= 5.0V, I
D
= 0.05A
V
GS
= 10V, I
D
= 0.5A
On-State Drain Current
I
D(ON)
0.5
1.0
A
V
GS
= 10V, V
DS
= 7.5V
Forward Transconductance
g
FS
80
mS V
DS
= 10V, I
D
= 0.2A
DYNAMIC CHARACTERISTICS (Note 7)
Input Capacitance
C
iss
22
50
pF
V
DS
= 25V, V
GS
= 0V
f = 1.0MHz
Output Capacitance
C
oss
11
25
pF
Reverse Transfer Capacitance
C
rss
2.0
5.0
pF
SWITCHING CHARACTERISTICS (Note 7)
Turn-On Delay Time
t
D(ON)
7.0
20
ns
V
DD
= 30V, I
D
= 0.2A,
R
L
= 150Ω,
V
GEN
= 10V,
R
GEN
= 25Ω
Turn-Off Delay Time
t
D(OFF)
11
20
ns
Notes:
5. Device mounted on FR-4 PCB 1.0 x 0.75 x 0.062 inch pad layout as shown on Diodes, Inc. suggested pad layout AP02001, which can be found on our
website at
6. Short duration pulse test used to minimize self-heating effect.
7. Guaranteed by design. Not subject to production testing.
