BCV46
Document Number: DS33002 Rev. 4 - 2
3 of 5
January 2013
© Diodes Incorporated
BCV46
A Product Line of
Diodes Incorporated
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol
Min
Typ
Max
Unit
Test
Condition
OFF CHARACTERISTICS
Collector-Base Breakdown Voltage
BV
CBO
-80 - - V
I
C
= -100µA
Collector-Emitter Breakdown Voltage (Note 9)
BV
CEO
-60 - - V
I
C
= -10mA
Emitter-Base Breakdown Voltage
BV
EBO
-10 - - V
I
E
= -10µA
Collector Cutoff Current
I
CBO
-
-
<1
-
-100
-10
nA
µA
V
CB
= -60V
V
CB
= -60V, T
A
= +150°C
Emitter Cutoff Current
I
EBO
- <1
-100 nA
V
EB
= -4V
ON CHARACTERISTICS (Note 9)
Static Forward Current Transfer Ratio
h
FE
2,000
4,000
10,000
2,000
-
-
-
-
-
-
-
-
-
I
C
= -100µA, V
CE
= -1V
I
C
= -10mA, V
CE
= -5V
I
C
= -100mA, V
CE
= -5V
I
C
= -500mA, V
CE
= -5V
Collector-Emitter Saturation Voltage
V
CE(sat)
- -
-1.0 V
I
C
= - 100mA, I
B
= -0.1mA
Base-Emitter Saturation Voltage
V
BE(sat)
- -
-1.5 V
I
C
= -100mA, I
B
= -0.1mA
SMALL SIGNAL CHARACTERISTICS
Transition Frequency
f
T
- 200 - MHz
V
CE
= -5V, I
C
= -50mA,
f = 20MHz
Output Capacitance
C
obo
- 4.5 - pF
V
CB
= -10V, f = 1MHz
Notes:
9. Measured under pulsed conditions. Pulse width ≤ 300µs. Duty cycle ≤ 2%.
