New prod uc t, Electrical characteristics – Diodes DDTA (R1-ONLY SERIES) CA User Manual
Page 2

DS30335 Rev. 6 - 2
2 of 4
www.diodes.com
DDTA (R1-ONLY SERIES) CA
© Diodes Incorporated
NEW PROD
UC
T
Electrical Characteristics
@T
A
= 25°C unless otherwise specified
Characteristic
Symbol
Min
Typ
Max
Unit
Test Condition
Collector-Base Breakdown Voltage
BV
CBO
-50
⎯
⎯
V
I
C
= -50
μA
Collector-Emitter Breakdown Voltage
BV
CEO
-50
⎯
⎯
V
I
C
= -1mA
Emitter-Base Breakdown Voltage
BV
EBO
-5
⎯
⎯
V
I
E
= -50
μA
Collector Cutoff Current
I
CBO
⎯
⎯
-0.5
μA V
CB
= -50V
Emitter Cutoff Current
I
EBO
⎯
⎯
-0.5
μA V
EB
= -4V
Collector-Emitter Saturation Voltage
V
CE(sat)
⎯
⎯
-0.3
V
I
C/
I
B
= -10mA/-1mA DDTA113TCA
I
C/
I
B
= -5mA/-0.5mA DDTA123TCA
I
C/
I
B
= -2.5mA/-.25mA DDTA143TCA
I
C/
I
B
= -1mA/-.1mA DDTA114TCA
I
C/
I
B
= -5mA/-0.5mA DDTA124TCA
I
C/
I
B
= -2.5mA/-.25mA DDTA144TCA
I
C/
I
B
= -1mA/-0.1mA DDTA115TCA
I
C/
I
B
= -.5mA/-.05mA DDTA125TCA
DC Current Transfer Ratio
h
FE
100
250
600
⎯ I
C
= -1mA, V
CE
= -5V
Input Resistor (R
1
) Tolerance
ΔR
1
-30
⎯
+30
%
⎯
Gain-Bandwidth Product*
f
T
⎯
250
⎯
MHz
V
CE
= -10V, I
E
= 5mA,
f = 100MHz
* Transistor - For Reference Only
