DCX (LO-R1) H
© Diodes Incorporated
DCX (LO-R1) H
DCX (LO-R1) H
COMPLEMENTARY NPN/PNP PRE-BIASED SMALL SIGNAL DUAL SURFACE MOUNT TRANSISTOR
Features
•
Epitaxial Planar Die Construction
•
Built-In Biasing Resistors
•
Lead Free By Design/RoHS Compliant (Note 3)
•
"Green" Device (Note 4 and 5)
Mechanical Data
•
Case: SOT-563
•
Case Material: Molded Plastic. UL Flammability
Classification Rating 94V-0
•
Moisture Sensitivity: Level 1 per J-STD-020C
•
Terminals: Finish - Matte Tin annealed over Alloy 42
leadframe. Solderable per MIL-STD-202, Method 208
•
Terminal Connections: See Diagram
•
Weight: 0.005 grams (approximate)
P/N
R1 (NOM)
R2 (NOM)
MARKING
DCX122LH
DCX142JH
DCX122TH
DCX142TH
0.22K
Ω
0.47K
Ω
0.22K
Ω
0.47K
Ω
10K
Ω
10K
Ω
OPEN
OPEN
C81
C82
C83
C84
N
E
P
D
UC
P
D
UC
W
R
O
T
T
R
O
SOT-563
Dim
Min Max Typ
A
0.15
0.30 0.25
B
1.10
1.25 1.20
C
1.55
1.70 1.60
D
0.50
G
0.90
1.10 1.00
H
1.50
1.70 1.60
K
0.56
0.60 0.60
L
0.15
0.25 0.20
M
0.10
0.18 0.11
All Dimensions in mm
A
M
L
Maximum Ratings NPN Section
@T
A
= 25°C unless otherwise specified
Characteristic
Symbol
Value
Unit
Supply Voltage
V
CC
50
V
Input Voltage
DCX122LH
DCX142JH
V
IN
-5 to +6
-5 to +6
V
Input Voltage DCX122TH
DCX142TH
V
EBO (MAX)
5
V
Output Current All
I
C
100
mA
Power Dissipation (Note 1, 2)
P
d
150
mW
Thermal Resistance, Junction to Ambient Air (Note 1)
R
θJA
833
°C/W
Operating and Storage Temperature Range
T
j
, T
STG
-55 to +150
°C
Notes:
1. Mounted on FR4 PC Board with recommended pad layout at http://www.diodes.com/datasheets/ap02001.pdf.
2. NPN Section, PNP Section, or maximum combined.
3. No purposefully added lead.
4. Diodes Inc.'s "Green" policy can be found on our website at http://www.diodes.com/products/lead_free/index.php.
5. Product manufactured with Date Code UO (week 40, 2007) and newer are built with Green Molding Compound. Product manufactured prior to Date
Code UO are built with Non-Green Molding Compound and may contain Halogens or Sb2O3 Fire Retardants.
R
1
, R
2
R
1
Only
SCHEMATIC DIAGRAM, TOP VIEW
R
1
R
1
R
1
R
1
R
2
R
2
B C
H
K
G
D
CXXYM
