Diodes DDC (xxxx) H User Manual
Nxxym, Features, Mechanical data

DDC (xxxx) H
NPN PRE-BIASED SMALL SIGNAL DUAL SURFACE MOUNT TRANSISTOR
Features
DS30421 Rev. 4 - 2
1 of 4
www.diodes.com
DDC (xxxx) H
© Diodes Incorporated
•
Epitaxial Planar Die Construction
•
Complementary PNP Types Available
(DDA)
•
Built-In Biasing Resistors
•
Lead Free By Design/RoHS Compliant (Note 3)
•
"Green" Device (Note 4 and 5)
Mechanical Data
•
Case: SOT-563
•
Case Material: Molded Plastic. UL Flammability
Classification Rating 94V-0
•
Moisture Sensitivity: Level 1 per J-STD-020C
•
Terminals: Finish - Matte Tin annealed over Alloy 42
leadframe. Solderable per MIL-STD-202, Method 208
•
Terminal Connections: See Diagram
•
Weight: 0.005 grams (approximate)
P/N
R1
R2
MARKING
DDC124EH
DDC144EH
DDC143EH
DDC114YH
DDC123JH
DDC114EH
DDC143TH
DDC114TH
22K
Ω
47K
Ω
4.7K
Ω
10K
Ω
2.2K
Ω
10K
Ω
4.7K
Ω
10K
Ω
22K
Ω
47K
Ω
4.7K
Ω
47K
Ω
47K
Ω
10K
Ω
⎯
⎯
N17
N20
N08
N14
N06
N13
N07
N12
SOT-563
Dim
Min
Max Typ
A
0.15
0.30 0.25
B
1.10
1.25 1.20
C
1.55
1.70 1.60
D
0.50
G
0.90
1.10 1.00
H
1.50
1.70 1.60
K
0.56
0.60 0.60
L
0.15
0.25 0.20
M
0.10
0.18 0.11
All Dimensions in mm
Maximum Ratings
@T
A
= 25°C unless otherwise specified
A
M
L
Characteristic
Symbol
Value
Unit
Supply Voltage (6) to (1) and (3) to (4)
V
CC
50
V
Input Voltage (2) to (1) and (5) to (4)
DDC124EH
DDC144EH
DDC143EH
DDC114YH
DDC123JH
DDC114EH
DDC143TH
DDC114TH
V
IN
-10 to +40
-10 to +40
-10 to +30
-6 to +40
-5 to +12
-10 to +40
-5V max
-5V max
V
Output Current DDC124EH
DDC144EH
DDC143EH
DDC114YH
DDC123JH
DDC114EH
DDC143TH
DDC114TH
I
O
30
30
100
70
100
50
100
100
mA
Output Current
All
I
C
(Max)
100
mA
Power Dissipation
P
d
150
mW
Thermal Resistance, Junction to Ambient Air (Note 2)
R
θJA
833
°C/W
Operating and Storage Temperature Range
T
j
, T
STG
-55 to +150
°C
Notes:
1. Package is non-polarized. Parts may be on reel in orientation illustrated, 180° rotated, or mixed (both ways).
2. Mounted on FR4 Board with recommended pad layout at http://www.diodes.com/datasheets/ap02001.pdf.
3. No purposefully added lead.
4. Diodes Inc.'s "Green" policy can be found on our website at http://www.diodes.com/products/lead_free/index.php.
5. Product manufactured with Date Code UO (week 40, 2007) and newer are built with Green Molding Compound. Product manufactured prior to Date
Code UO are built with Non-Green Molding Compound and may contain Halogens or Sb2O3 Fire Retardants.
R
1
, R
2
R
1
Only
SCHEMATIC DIAGRAM, TOP VIEW
R
1
R
1
6
5
4
3
2
1
R
1
R
1
R
2
6
5
4
3
2
1
R
2
B C
H
K
G
D
NXXYM
SEE NOTE 1
