DDA (LO-R1) U

PNP PRE-BIASED SMALL SIGNAL DUAL SURFACE MOUNT TRANSISTOR

Features

Epitaxial Planar Die Construction

Complementary NPN Types Available (DDC)

Built-In Biasing Resistors

Lead-Free/RoHS Compliant (Note 3)

"Green" Device (Note 4 and 5)

Mechanical Data

Case: SOT-363

Case Material: Molded Plastic, “Green” Molding
Compound. UL Flammability Classification Rating 94V-0

Moisture Sensitivity: Level 1 per J-STD-020C

Terminals: Finish - Matte Tin Solderable per
MIL-STD-202, Method 208

Lead Free Plating (Matte Tin Finish annealed over
Alloy 42 leadframe).

Terminal Connections: See Diagram

Marking Information: See Page 3

Type Code: See Table Below

Ordering Information: See Page 3

Weight: 0.0058 grams (approximate)


P/N

R1 (NOM)

R2 (NOM) Type Code

DDA122LU
DDA142JU
DDA122TU
DDA142TU

0.22K
0.47K
0.22K
0.47K

10K
10K

OPEN
OPEN

P81
P82
P83
P84






SOT-363

Dim

Min

Max

A

0.10

0.30

B

1.15

1.35

C

2.00

2.20

D

0.65 Nominal

F

0.30

0.40

H

1.80

2.20

J

0.10

K

0.90

1.00

L

0.25

0.40

M

0.10

0.25

α

0

°

All Dimensions in mm

A

M

J

L

D

B C

H

K

F

R

1

R

1

R

2

6

5

4

3

2

1

R

2

R

1

R

1

6

5

4

3

2

1

R

1

, R

2

R

1

Only

SCHEMATIC DIAGRAM

Maximum Ratings NPN Section

@T

A

= 25°C unless otherwise specified

Characteristic

Symbol

Value

Unit

Supply Voltage (1) to (6) and (4) to (3)

V

CC

-50

V

Input Voltage (1) to (2) and (4) to (5)

DDA122LU

DDA142JU

V

IN

+5 to -6
+5 to -6

V

Input Voltage (1) to (2) and (4) to (5)

DDA122TU

DDA142TU

V

EBO (MAX)

-5

V

Output Current All

I

C

-100

mA

Power Dissipation (Note 2)

P

d

200

mW

Thermal Resistance, Junction to Ambient Air (Note 2)

R

θJA

625

°C/W

Operating and Storage Temperature Range

T

j

, T

STG

-55 to +150

°C

Notes:

1. Mounted on FR4 PC Board with recommended pad layout at http://www.diodes.com/datasheets/ap02001.pdf.
2. 150mW per element must not be exceeded.
3. No purposefully added lead.
4. Diodes Inc.'s "Green" policy can be found on our website at http://www.diodes.com/products/lead_free/index.php.
5. Product manufactured with Date Code UO (week 40, 2007) and newer are built with Green Molding Compound. Product manufactured prior to Date

Code UO are built with Non-Green Molding Compound and may contain Halogens or Sb2O3 Fire Retardants.






DS30423 Rev. 7 - 2

1 of 3

www.diodes.com

DDA (LO-R1) U

© Diodes Incorporated
