DS30422 Rev. 3 - 2

1 of 6

www.diodes.com

DCX (xxxx) H

© Diodes Incorporated

DCX (xxxx) H

DCX (xxxx) H

COMPLEMENTARY NPN/PNP PRE-BIASED SMALL SIGNAL DUAL SURFACE MOUNT TRANSISTOR

Features

Epitaxial Planar Die Construction

Built-In Biasing Resistors

Lead Free By Design/RoHS Compliant (Note 2)

"Green" Device (Note 3 and 4)

Mechanical Data

Case: SOT-563

Case Material: Molded Plastic. UL Flammability
Classification Rating 94V-0

Moisture Sensitivity: Level 1 per J-STD-020C

Terminals: Finish - Matte Tin annealed over Alloy 42
leadframe. Solderable per MIL-STD-202, Method 208

Terminal Connections: See Diagram

Weight: 0.005 grams (approximate)


P/N

R1

R2

MARKING

DCX124EH
DCX144EH
DCX143EH
DCX114YH

DCX123JH

DCX114EH
DCX143TH
DCX114TH

22K

Ω

47K

Ω

4.7K

Ω

10K

Ω

2.2K

Ω

10K

Ω

4.7K

Ω

10K

Ω

22K

Ω

47K

Ω

4.7K

Ω

47K

Ω

47K

Ω

10K

Ω


C17
C20
C08
C14
C06
C13
C07
C12

SOT-563

Dim

Min

Max Typ

A

0.15

0.30 0.25

B

1.10

1.25 1.20

C

1.55

1.70 1.60

D

0.50

G

0.90

1.10 1.00

H

1.50

1.70 1.60

K

0.56

0.60 0.60

L

0.15

0.25 0.20

M

0.10

0.18 0.11

All Dimensions in mm

A

M

L

B C

H

K

G

D

CXX YM

N

E

W

PP

R

UC

R

UC
O

D

T

T

O

D

R

1

R

1

R

2

R

2

R

1

R

1

Maximum Ratings NPN Section

@T

A

= 25°C unless otherwise specified

R

1

, R

2

R

1

Only

SCHEMATIC DIAGRAM, TOP VIEW

Characteristic

Symbol

Value

Unit

Supply Voltage

V

CC

50

V

Input Voltage

DCX124EH

DCX144EH

DCX143EH

DCX114YH

DCX123JH

DCX114EH

DCX143TH

DCX114TH

V

IN

-10 to +40
-10 to +40
-10 to +30

-6 to +40
-5 to +12

-10 to +40

-5V max
-5V max

V

Output Current DCX124EH

DCX144EH

DCX143EH

DCX114YH

DCX123JH

DCX114EH

DCX143TH

DCX114TH

I

O

30
30

100

70

100

50

100
100

mA

Output Current

All

I

C

(Max)

100

mA

Power Dissipation (Total)

P

d

150

mW

Thermal Resistance, Junction to Ambient Air (Note 1)

R

θJA

833

°C/W

Operating and Storage Temperature Range

T

j

, T

STG

-55 to +150

°C

Notes:

1. Mounted on FR4 Board with recommended pad layout at http://www.diodes.com/datasheets/ap02001.pdf.
2. No purposefully added lead.
3. Diodes Inc.'s "Green" policy can be found on our website at http://www.diodes.com/products/lead_free/index.php.
4. Product manufactured with Date Code UO (week 40, 2007) and newer are built with Green Molding Compound. Product manufactured prior to Date

Code UO are built with Non-Green Molding Compound and may contain Halogens or Sb2O3 Fire Retardants.
