BSR43
Da
tasheet Number: DS33018 Rev. 5 - 2
4 of 7
November 2013
© Diodes Incorporated
BSR43
A Product Line of
Diodes Incorporated
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol
Min
Typ.
Max
Unit
Test
Condition
Collector-Base Breakdown Voltage
BV
CBO
90 – – V
I
C
= 100µA
Collector-Emitter Breakdown Voltage (Note 11)
BV
CEO
80 – – V
I
C
= 10mA
Emitter-Base Breakdown Voltage
BV
EBO
5 – – V
I
E
= 100µA
Collector Cutoff Current
I
CBO
– –
100
50
nA
µA
V
CB
= 60V
V
CB
= 60V, T
J
= +150°C
DC current transfer Static ratio (Note 11)
h
FE
30
100
50
–
–
–
–
300
–
–
I
C
= 100µA, V
CE
= 5V
I
C
= 100mA, V
CE
= 5V
I
C
= 500mA, V
CE
= 5V
Collector-Emitter Saturation Voltage (Note 11)
V
CE(sat)
–
–
–
–
0.25
0.5
V
I
C
= 150mA, I
B
= 15mA
I
C
= 500mA, I
B
= 50mA
Base-Emitter Saturation Voltage (Note 11)
V
BE(sat)
– –
1.0
1.2
V
I
C
= 150mA, I
B
= 15mA
I
C
= 500mA, I
B
= 50mA
Transitional Frequency
f
T
100 – – MHz
I
C
= 50mA, V
CE
= 10V
f = 35MHz
Output capacitance
C
obo
– – 12 pF
V
CB
= 10V, f = 1MHz
Input Capacitance
C
ibo
– – 90 pF
V
CB
= 0.5V, f = 1MHZ
Turn-On Time
T
on
– –
250 ns
V
CC
=20V, I
C
=100mA
I
B1
=I
B2
=5mA
Turn-Off Time
T
off
– –
1000
ns
Note:
11. Measured under pulsed conditions. Pulse width ≤ 300μs. Duty cycle ≤ 2%.
