BCP 51 / 52 / 53
Datasheet Number: DS35366 Rev. 5 – 2
2 of 7
March 2014
© Diodes Incorporated
BCP 51/ 52/ 53
Absolute Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
Characteristic
Symbol
BCP51 BCP52 BCP53
Unit
Collector-Base Voltage
V
CBO
-45 -60 -100 V
Collector-Emitter Voltage
V
CEO
-45 -60 -80 V
Emitter-Base Voltage
V
EBO
-5 V
Continuous Collector Current
I
C
-1
A
Peak Pulse Collector Current
I
CM
-2
Continuous Base Current
I
B
-100
mA
Peak Pulse Base Current
I
BM
-200
Thermal Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol
Value
Unit
Power Dissipation
(Note 6)
P
D
2 W
Thermal Resistance, Junction to Ambient
(Note 6)
R
θJA
62
C/W
Thermal Resistance, Junction to Leads
(Note 7)
R
θJL
19.4
C/W
Operating and Storage Temperature Range
T
J,
T
STG
-65 to +150
C
ESD Ratings
(Note 8)
Characteristic Symbol
Value
Unit
JEDEC
Class
Electrostatic Discharge - Human Body Model
ESD HBM
4,000
V
3A
Electrostatic Discharge - Machine Model
ESD MM
400
V
C
Notes:
6. For a device mounted with the collector lead on 50mm x 50mm 1oz copper that is on a single-sided 1.6mm FR4 PCB; device is measured under still air
conditions whilst operating in steady-state.
7. Thermal resistance from junction to solder-point (at the end of the collector lead).
8. Refer to JEDEC specification JESD22-A114 and JESD22-A115.
