BC847BFA
Document number: DS36019 Rev. 1 - 2
3 of 6
July 2013
© Diodes Incorporated
BC847BFA
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol
Min
Typical
Max
Unit
Test
Condition
OFF CHARACTERISTICS
Collector-Base Breakdown Voltage
BV
CBO
50 150
V
I
C
= 50µA, I
B
= 0
Collector-Emitter Breakdown Voltage
BV
CES
50 150
I
C
= 50µA, I
B
= 0
Collector-Emitter Breakdown Voltage (Note 8)
BV
CEO
45 65
V
I
C
= 1mA, I
B
= 0
Collector-Base Breakdown Voltage
BV
EBO
6.0 8.35
V
I
E
= 50
A, I
C
= 0
Collector-Base Cutoff Current
I
CBO
15 nA
V
CB
= 40V
Collector-Emitter Cutoff Current
I
CES
15 nA
V
CE
= 40V
ON CHARACTERISTICS (Note 8)
DC Current Gain
h
FE
100
200
220
260
470
I
C
= 10µA, V
CE
= 5.0V
I
C
= 2.0mA, V
CE
= 5.0V
Collector-Emitter Saturation Voltage
V
CE(sat)
50
122
125
300
mV
I
C
= 10mA, I
B
= 0.5mA
I
C
= 100mA, I
B
= 5.0mA
Base-Emitter Saturation Voltage
V
BE(sat)
760
880
1000
1100
mV
I
C
= 10mA, I
B
= 0.5mA
I
C
= 100mA, I
B
= 5.0mA
Base-Emitter Voltage
V
BE(on)
580
650
725
750
800
mV
I
C
= 2.0mA, V
CE
= 5V
I
C
= 10mA, V
CE
= 5V
SMALL SIGNAL CHARACTERISTICS
Output Capacitance
C
obo
1.5
pF
V
CB
= 10.0V, f = 1.0MHz, I
E
= 0
Current Gain-Bandwidth Product
f
T
100 170
MHz
V
CE
= 5V, I
C
= 10mA,
f = 100MHz
Notes:
8. Measured under pulsed conditions. Pulse width
300µs. Duty cycle 2%.
