2DC4617Q/R/S
NPN SMALL SIGNAL SURFACE MOUNT TRANSISTOR
Features
•
Ultra Miniature Surface Mount Package
•
Complementary PNP Type Available (2DA1774Q,R,S)
•
Lead Free/RoHS Compliant (Note 3)
•
"Green" Device (Note 4 and 5)
Mechanical Data
•
Case: SOT-523
•
Case Material: Molded Plastic. UL Flammability
Classification Rating 94V-0
•
Moisture Sensitivity: Level 1 per J-STD-020C
•
Terminal Connections: See diagram
•
Terminals: Solderable per MIL-STD-202, Method 208
•
Lead Free Plating (Matte Tin annealed over Alloy 42
leadframe).
•
Marking Information: (See Page 3): 2DC4617Q: 8D
2DC4617R: 8E
2DC4617S: 8F
•
Ordering Information: See Page 3
•
Weight: 0.002 grams (approximate)
A
M
J
L
D
B
N
C
H
K
G
C
E
B
SOT-523
Dim
Min
Max
Typ
A
0.15
0.30
0.22
B
0.75
0.85
0.80
C
1.45
1.75
1.60
D
⎯
⎯
0.50
G
0.90
1.10
1.00
H
1.50
1.70
1.60
J
0.00
0.10
0.05
K
0.60
0.80
0.75
L
0.10
0.30
0.22
M
0.10
0.20
0.12
N
0.45 0.65 0.50
α
0
°
8
°
⎯
All Dimensions in mm
Maximum Ratings
@T
A
= 25°C unless otherwise specified
DS30252 Rev. 9 - 2
1 of 3
www.diodes.com
2DC4617Q/R/S
© Diodes Incorporated
Characteristic
Symbol
Value
Unit
Collector-Base Voltage
V
CBO
60
V
Collector-Emitter Voltage
V
CEO
50
V
Emitter-Base Voltage
V
EBO
7.0
V
Collector Current - Continuous (Note 1)
I
C
150
mA
Thermal Characteristics
@T
A
= 25°C unless otherwise specified
Characteristic
Symbol
Value
Unit
Power Dissipation (Note 1)
P
d
150
mW
Thermal Resistance, Junction to Ambient (Note 1)
R
θJA
833
°C/W
Operating and Storage Temperature Range
T
j
, T
STG
-55 to +150
°C
Electrical Characteristics
@T
A
= 25°C unless otherwise specified
Characteristic
Symbol
Min
Typ Max Unit
Test Condition
OFF CHARACTERISTICS (Note 2)
Collector-Base Breakdown Voltage
V
(BR)CBO
60
⎯
⎯
V
I
C
= 50
μA, I
E
= 0
Collector-Emitter Breakdown Voltage
V
(BR)CEO
50
⎯
⎯
V
I
C
= 1.0mA, I
B
= 0
Emitter-Base Breakdown Voltage
V
(BR)EBO
7.0
⎯
⎯
V
I
E
= 50
μA, I
C
= 0
Collector Cutoff Current
I
CBO
⎯
⎯ 100 nA V
CB
= 60V
Emitter Cutoff Current
I
EBO
⎯
⎯ 100 nA V
EB
= 7.0V
ON CHARACTERISTICS (Note 2)
DC Current Gain 2DC4617Q
2DC4617R
2DC4617S
h
FE
120
180
270
⎯
⎯
⎯
270
390
560
⎯ V
CE
= 6.0V, I
C
= 1.0mA
Collector-Emitter Saturation Voltage
V
CE(SAT)
⎯
⎯ 0.4
V
I
C
= 50mA, I
B
= 5.0mA
SMALL SIGNAL CHARACTERISTICS
Output Capacitance
C
obo
⎯
2.0
3.5
pF V
CB
= 12V, f = 1.0MHz, I
E
= 0
Current Gain-Bandwidth Product
f
T
⎯
180
⎯ MHz V
CE
= 12V, I
E
= -2mA, f = 1MHz
Current Gain-Bandwidth Product
f
T
180 Typ.
⎯ MHz V
CE
= 12V, I
E
= 0A, f = 1MHz
Current Gain-Bandwidth Product
f
T
180 Typ.
⎯ MHz V
CE
= 12V, I
C
= -2.0mA,
f = 100MHz
Notes:
1. Part mounted on FR-4 board with recommended pad layout, which can be found on our website at http://www.diodes.com/datasheets/ap02001.pdf.
2. Short duration pulse test used to minimize self-heating effect.
3. No purposefully added lead.
4. Diodes Inc.'s "Green" policy can be found on our website at http://www.diodes.com/products/lead_free/index.php.
5. Product manufactured with Date Code UO (week 40, 2007) and newer are built with Green Molding Compound. Product manufactured prior to Date
Code UO are built with Non-Green Molding Compound and may contain Halogens or Sb2O3 Fire Retardants.
