BZT52B15LP
Document number: DS36252 Rev. 1 - 2
1 of 4
April 2013
© Diodes Incorporated
BZT52B15LP
NEW PROD
UC
T
SURFACE MOUNT PRECISION ZENER DIODE
Features
Small Leadless Surface Mount Package
Ideally Suited for Automated Assembly Processes
Tight Tolerance on Zener Breakdown Voltage (±2%)
Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2)
Halogen and Antimony Free. “Green” Device (Note 3)
Mechanical Data
Case:
X1-DFN1006-2
Case Material: Molded Plastic, "Green" Molding Compound.
UL Flammability Classification Rating 94V-0
Moisture Sensitivity: Level 1 per J-STD-020
Terminal Connections: Cathode Bar (See Marking Information)
Terminals: Finish – NiPdAu Over Copper Leadframe.
Solderable per MIL-STD-202, Method 208
Weight: 0.001 grams (approximate)
Ordering Information
(Note 4)
Part Number
Case
Packaging
BZT52B15LP-7B
X1-DFN1006-2
10,000/Tape & Reel
Notes:
1. No purposely added lead. Fully EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant.
2. S more information about Diodes Incorporated’s definitions of Halogen- and Antimony-free, "Green"
and Lead-free.
3. Halogen- and Antimony-free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl) and
<1000ppm antimony compounds.
4. For packaging details, go to our website at http”
Marking Information
Bottom View
6L= Product Type Marking Code:
X1-DFN1006-2
e4
6L
