BAW56DW
Document number: DS30146 Rev. 11 - 2
2 of 4
May 2013
© Diodes Incorporated
BAW56DW
Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
Characteristic
Symbol
Value
Unit
Non-Repetitive Peak Reverse Voltage
V
RM
100
V
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
V
RRM
V
RWM
V
R
75
V
RMS Reverse Voltage
V
R(RMS)
53
V
Forward Continuous Current (Note 5)
I
FM
300
mA
Average Rectified Output Current (Note 5)
I
O
150
mA
Non-Repetitive Peak Forward Surge Current
@ t = 1.0µs
@ t = 1.0s
I
FSM
2.0
1.0
A
Thermal Characteristics
Characteristic
Symbol
Value
Unit
Power Dissipation (Note 5)
P
D
200
mW
Thermal Resistance Junction to Ambient Air (Note 5)
R
θJA
625
°C/W
Operating and Storage Temperature Range
T
J
, T
STG
-65 to +150
°C
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic
Symbol
Min
Max
Unit
Test Condition
Reverse Breakdown Voltage (Note 6)
V
(BR)R
75 — V
I
R
= 2.5µA
Forward Voltage
V
F
—
0.715
0.855
1.0
1.25
V
I
F
= 1.0mA
I
F
= 10mA
I
F
= 50mA
I
F
= 150mA
Reverse Current (Note 6)
I
R
—
2.5
50
30
25
µA
µA
µA
nA
V
R
= 75V
V
R
= 75V, T
J
= +150°C
V
R
= 25V, T
J
= +150°C
V
R
= 20V
Total Capacitance
C
T
—
2.0
pF
V
R
= 0, f = 1.0MHz
Reverse Recovery Time
t
rr
—
4.0
ns
I
F
= I
R
= 10mA,
I
rr
= 0.1 x I
R
, R
L
= 100Ω
Notes:
5. Device mounted on FR-4 PC board with recommended pad layout, which can be found on our website at
6. Short duration pulse test used to minimize self-heating effect.
