SURFACE MOUNT SWITCHING DIODE ARRAY
Features
•
Fast Switching Speed
•
Low Profile DFN Package (0.575mm typical thickness) is Much
Thinner than Conventional SOT Style Packages
•
Thermally Efficient DFN Package Features 500mW Power
Dissipation Capability in a Compact 2.0 * 2.0mm Footprint
•
Two “BAV99” Circuits In One Package
•
Lead Free/RoHS Compliant (Note 1)
•
"Green" Device (Note 2)
Mechanical Data
• Case:
DFN2020B-6
•
Case Material: Molded Plastic, “Green” Molding Compound.
UL Flammability Classification Rating 94V-0
•
Moisture Sensitivity: Level 1 per J-STD-020
•
Terminals: NiPdAu over Copper leadframe (Lead Free Plating).
Solderable per MIL-STD-202, Method 208
•
Polarity: See Diagram
•
Weight: 0.006 grams (approximate)
Ordering Information
(Note 3)
Part Number
Case
Packaging
BAV99BRLP-7
DFN2020B-6
3000/Tape & Reel
Notes:
1. No purposefully added lead.
2. Diodes Inc.'s "Green" policy can be found on our w3. For packaging details, go to our website at
Marking Information
Date Code Key
Year
2011
2012
2013
2014
2015
2016
2017
Code Y
Z
A
B
C D
E
Month
Jan
Feb
Mar
Apr
May
Jun
Jul
Aug
Sep
Oct
Nov
Dec
Code 1 2 3 4 5 6 7 8 9 O N D
Top View
DFN2020B-6
Top View
Internal Schematic
CK = Product Type Marking Code
YM = Date Code Marking
Y = Year (ex: Y = 2011)
M = Month (ex: 9 = September)
Bottom View
Pin 1 = A1 (anode 1, right below the
notch indication)
Pin 2 = C1 (cathode 1)
Pin 3 = AC2 (internally connected to
rectangular pad)
Pin 4 = A2 (anode 2)
Pin 5 = C2 (cathode 2)
Pin 6 = AC1 (internally connected to
the pad with a notch)
