BAV5004W
NEW PROD
UC
T
Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol
Value
Unit
Repetitive Peak Reverse Voltage
V
RRM
400 V
Working Peak Reverse Voltage
DC Blocking Voltage
V
RWM
V
R
350 V
RMS Reverse Voltage
V
R(RMS)
247 V
Forward Continuous Current (Note 5)
I
FM
300 mA
Peak Repetitive Forward Current (Note 5)
I
FRM
625 mA
Non-Repetitive Peak Forward Surge Current
@ t = 1.0µs
@ t = 1.0ms
I
FSM
5.0
3.0
A
Thermal Characteristics
Characteristic Symbol
Value
Unit
Power Dissipation (Note 5) (See figure 1)
P
D
300 mW
Thermal Resistance Junction to Ambient Air (Note 5)
R
θJA
417 °C/W
Operating and Storage Temperature Range
T
J
, T
STG
-55 to +150
°C
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol
Min
Typ
Max
Unit
Test
Condition
Reverse Breakdown Voltage (Note 6)
V
(BR)R
400
V
I
R
= 150µA
Forward Voltage
V
F
0.93
1.09
1.29
V
I
F
= 20mA
I
F
= 100mA
I
F
= 200mA
Reverse Current (Note 6)
I
R
1
100
µA
µA
V
R
= 240V
V
R
= 240V, T
J
= +150°C
Total Capacitance
C
T
0.9 2.5 pF
V
R
= 0V, f = 1.0MHz
Reverse Recovery Time
t
rr
50 ns
I
F
= I
R
= 30mA,
I
rr
= 3.0mA, R
L
= 100Ω
Notes:
5. Part mounted on FR-4 board with recommended pad layout, which can be found on our websit6. Short duration pulse test used to minimize self-heating effect.
0
50
100
25
50
75
100
125
150
P
, P
O
WE
R
DI
SSI
P
A
T
IO
N (
m
W
)
D
T , AMBIENT TEMPERATURE (°C)
A
Fig. 1 Power Derating Curve
150
200
250
0
Note 5
300
350
1,000
V , INSTANTANEOUS FORWARD VOLTAGE (V)
Fig. 2 Typical Forward Characteristics
F
0
0.2
0.4
0.6
0.8
1.0
1.4
1.2
100
10
1
0.1
0.01
0.001
I,
I
N
S
TA
N
TA
N
E
O
U
S F
O
R
WA
R
D
C
U
R
R
E
N
T
(A
)
F
m
T = 25 C
J
°
T =
5 C
J
-5
°
T = 8 C
J
°
5
T = 12 C
J
°
5
T = 1 0 C
J
°
5
