BAV19W - BAV21W
Document number: DS12024 Rev. 21 - 2
3 of 4
www.diodes.com
October 2013
© Diodes Incorporated
BAV19W - BAV21W
Package Outline Dimensions
Please see AP02002 at http://www.diodes.com/datasheets/ap02002.pdf for latest version.
Suggested Pad Layout
Please see AP02001 at http://www.diodes.com/datasheets/ap02001.pdf for the latest version.
0.0001
0.01
0.001
0.1
1
10
100
0 50 100 200 150 250
V , INSTANTANEOUS REVERSE VOLTAGE (V)
Fig. 3 Typical Reverse Characteristics
R
0.0
0.5
1.0
1.5
3.5
3.0
2.5
2.0
4.0
0 10 20 40 30
C
, T
O
TAL
C
A
P
A
C
IT
AN
C
E (
pF
)
T
V , DC REVERSE VOLTAGE (V)
Fig. 4 Total Capacitance vs. Reverse Voltage
R
SOD123
Dim Min Max
A 0.55 Typ
B 1.40 1.70
C 3.55 3.85
H 2.55 2.85
J 0.00 0.10
K 1.00 1.35
L 0.25 0.40
M 0.10 0.15
 0 8°
All Dimensions in mm
Dimensions Value (in mm)
G 2.250
X 0.900
X1 4.050
Y 0.950
K
L
M
C
H
B A
Y
X
X1
G
