BAV199DW
Document number: DS30417 Rev. 9 - 2
1 of 4
www.diodes.com
August 2009
© Diodes Incorporated
BAV199DW
Features
•
Surface Mount Package Ideally Suited for Automated Insertion
•
Very Low Leakage Current
•
Lead Free/RoHS Compliant (Note 3)
•
"Green" Device (Notes 4 and 5)
•
Qualified to AEC-Q101 Standards for High Reliability
Mechanical Data
• Case:
SOT-363
•
Case Material: Molded Plastic. UL Flammability Classification
Rating 94V-0
•
Moisture Sensitivity: Level 1 per J-STD-020
•
Terminals: Finish - Matte Tin annealed over Alloy 42 leadframe
(Lead Free Plating). Solderable per MIL-STD-202, Method 208
•
Polarity: See Diagram
•
Marking Information: See Page 2
•
Ordering Information: See Page 2
•
Weight: 0.008 grams (approximate)
Maximum Ratings
@T
A
= 25°C unless otherwise specified
Characteristic
Symbol
Value
Unit
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
V
RRM
V
RWM
V
R
85
V
RMS Reverse Voltage
V
R(RMS)
60
V
Forward Continuous Current (Note 2)
Single diode
Double
diode
I
FM
160
140
mA
Repetitive Peak Forward Current (Note 2)
I
FRM
500
mA
Non-Repetitive Peak Forward Surge Current
@ t = 1.0
μs
@ t = 1.0ms
@ t = 1.0s
I
FSM
4.0
1.0
0.5
A
Thermal Characteristics
Characteristic
Symbol
Value
Unit
Power Dissipation (Note 2)
P
D
200
mW
Thermal Resistance Junction to Ambient Air (Note 2)
R
θJA
625
°C/W
Operating and Storage Temperature Range
T
J
, T
STG
-65 to +150
°C
Electrical Characteristics
@T
A
= 25°C unless otherwise specified
Characteristic
Symbol
Min
Typ
Max
Unit
Test Condition
Reverse Breakdown Voltage (Note 1)
V
(BR)R
85
⎯
⎯
V
I
R
= 100
μA
Forward Voltage
V
F
⎯
⎯
0.90
1.0
1.1
1.25
V
I
F
= 1.0mA
I
F
= 10mA
I
F
= 50mA
I
F
= 150mA
Leakage Current (Note 1)
I
R
⎯
⎯
5.0
80
nA
nA
V
R
= 75V
V
R
= 75V, T
J
= 150
°C
Total Capacitance
C
T
⎯
2
⎯
pF
V
R
= 0, f = 1.0MHz
Reverse Recovery Time
t
rr
⎯
⎯
3.0
μs
I
F
= I
R
= 10mA,
I
rr
= 0.1 x I
R
, R
L
= 100
Ω
Notes:
1. Short duration pulse test used to minimize self-heating effect.
2. Part mounted on FR-4 PC board with recommended pad layout, which can be found on our website at
4. Diodes Inc.'s "Green" policy can be found on our websit
Code UO are built with Non-Green Molding Compound and may contain Halogens or Sb
2
O
3
Fire Retardants.
TOP VIEW
SOT-363
Internal Schematic
TOP VIEW
AC
1
AC
2
C
2
A
1
A
2
C
1
