Diodes BAS19W - BAS21W - Manual (Page 3)

BAS19W - BAS21W
Document number: DS30118 Rev. 14 - 2
3 of 4
www.diodes.com
February 2014
© Diodes Incorporated
BAS19W - BAS21W
0 100 200
250
200
150
50
100
0
T , AMBIENT TEMPERATURE ( C)
Fig. 1 Power Derating Curve
A
°
P
,
P
O
WE
R
DI
SSI
P
A
T
IO
N
(mW
)
D
Note 5
0.001
0.01
0.1
1
0 0.4 0.2 0. 6
I
, INS
TAN
TANE
O
U
S
F
O
R
WA
R
D
C
U
R
R
EN
T
(A
)
F
V , INSTANTANEOUS FORWARD VOLTAGE (V)
Fig. 2 Typical Forward Characteristics
F
0.8 1.2 1.0 1.4
0.0001
0.01
0.001
0.1
1
10
100
0 50 100 200 150 250
V , INSTANTANEOUS REVERSE VOLTAGE (V)
Fig. 3 Typical Reverse Characteristics
R
0.0
0.5
1.0
1.5
3.5
3.0
2.5
2.0
4.0
0 10 20 40 30
C
, T
O
TAL
C
A
P
A
C
IT
A
N
C
E (
pF
)
T
V , DC REVERSE VOLTAGE (V)
Fig. 4 Total Capacitance vs. Reverse Voltage
R
Package Outline Dimensions
Please see AP02002 at http://www.diodes.com/datasheets/ap02002.pdf for the latest version.
SOT323
Dim Min Max Typ
A 0.25 0.40 0.30
B 1.15 1.35 1.30
C 2.00 2.20 2.10
D - - 0.65
G 1.20 1.40 1.30
H 1.80 2.20 2.15
J 0.0 0.10 0.05
K 0.90 1.00 1.00
L 0.25 0.40 0.30
M 0.10 0.18 0.11
α 0° 8° -
All Dimensions in mm
A
M
J
L D
B C
H
K
G
