BAS16 / MMBD4148 / MMBD914
Document number: DS12003 Rev. 29 - 2
3 of 4
www.diodes.com
October 2013
© Diodes Incorporated
BAS16 / MMBD4148 / MMBD914
400
T , AMBIENT TEMPERATURE (°C)
Fig. 1 Power Derating Curve
A
P
, P
O
WE
R
D
ISSI
P
A
T
IO
N (
m
W
)
D
Note 6
200
100
300
0
500
0 100 200
0.1
1
0.01
0.001
0 1.5 1.0 0.5
I
, INS
TAN
TANE
O
U
S
F
O
R
WA
R
D
C
U
R
R
EN
T
(A
)
F
V , INSTANTANEOUS FORWARD VOLTAGE (V)
Fig. 2 Typical Forward Characteristics
F
0.1
1
10
100
1,000
10,000
0 20 40 60 80 100
V , INSTANTANEOUS REVERSE VOLTAGE (V)
Fig. 3 Typical Reverse Characteristics
R
I,
IN
S
TA
N
TA
N
E
O
U
S
R
EV
E
R
SE
C
U
R
R
E
N
T
(n
A
)
R 0.0
0.2
0.4
0.6
0.8
1.8
1.6
1.4
1.2
1.0
2.0
0 10 20 40 30
C
, T
O
TAL
C
A
P
A
C
IT
A
N
C
E (
p
F
)
T
V , DC REVERSE VOLTAGE (V)
Fig. 4 Total Capacitance vs. Reverse Voltage
R
Package Outline Dimensions
Please see AP02002 at http://www.diodes.com/datasheets/ap02002.pdf for latest version.
SOT23
Dim Min Max Typ
A 0.37 0.51 0.40
B 1.20 1.40 1.30
C 2.30 2.50 2.40
D 0.89 1.03 0.915
F 0.45 0.60 0.535
G 1.78 2.05 1.83
H 2.80 3.00 2.90
J 0.013 0.10 0.05
K 0.903 1.10 1.00
K1 - - 0.400
L 0.45 0.61 0.55
M 0.085 0.18 0.11
 0° 8° -
All Dimensions in mm
A
M
J L
D
F
B C
H
K
G
K1
