BAT54LP
Document number: DS30504 Rev. 12 - 2
2 of 4
December 2012
© Diodes Incorporated
BAT54LP
Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol
Value
Unit
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
V
RRM
V
RWM
V
R
30 V
Forward Continuous Current
I
F
200 mA
Repetitive Peak Forward Current
I
FRM
300 mA
Forward Surge Current
@ t < 1.0s
I
FSM
600 mA
Thermal Characteristics
Characteristic
Symbol
Value
Unit
Power Dissipation (Note 5)
P
D
250
mW
Thermal Resistance, Junction to Ambient Air (Note 5)
R
θJA
400
°C/W
Operating and Storage Temperature Range
T
J
, T
STG
-65 to +125
°C
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic
Symbol
Min
Typ
Max
Unit
Test Condition
Reverse Breakdown Voltage (Note 6)
V
(BR)R
30
⎯
⎯
V
I
R
= 100
μA
Forward Voltage
V
F
⎯
⎯
240
320
400
500
1000
mV
I
F
= 0.1mA
I
F
= 1mA
I
F
= 10mA
I
F
= 30mA
I
F
= 100mA
Reverse Leakage Current (Note 6)
I
R
⎯
⎯
2.0
μA
V
R
= 25V
Total Capacitance
C
T
⎯
⎯
10
pF
V
R
= 1.0V, f = 1.0MHz
Reverse Recovery Time
t
rr
⎯
⎯
5.0
ns
I
F
= 10mA through I
R
= 10mA
to I
R
= 1.0mA, R
L
= 100
Ω
Notes:
5. Part mounted on FR-4 PC board with recommended pad layout, which can be found on our website at
6. Short duration pulse test used to minimize self-heating effect.
0.1
1
10
100
1,000
0
V , INSTANTANEOUS FORWARD VOLTAGE (V)
Fig. 1 Typical Forward Characteristics
R
I
, IN
S
T
AN
T
ANE
O
U
S F
O
R
WA
R
D
C
U
R
R
EN
T
(mA
)
F
0.2
0.4
0.6
0.8
1.0
1.2
1.4
1.6
0.001
0.0001
0.00001
0.01
0.1
10
1
100
0
3
6
9
15
12
18
27
24
21
30
V , INSTANTANEOUS REVERSE VOLTAGE (V)
Fig. 2 Typical Reverse Characteristics
R
I,
I
N
S
T
A
N
T
A
N
E
O
U
S
R
EV
E
R
SE
C
U
R
R
E
N
T
(u
A
)
R
