BAT42WS / BAT43WS
Document number: DS30100 Rev. 14 - 2
3 of 4
www.diodes.com
June 2012
© Diodes Incorporated
BAT42WS / BAT43WS
0.1
1.0
10
100
0 200 400 600 800
I,
I
N
S
T
A
N
T
A
N
E
O
U
S
F
O
R
WA
R
D
C
U
R
R
E
N
T
(mA
)
F
V , INSTANTANEOUS FORWARD VOLTAGE (mV)
Fig. 1 Typical Forward Characteristics
F
T = -25ºC
A
T = 25ºC
A
T = 125ºC
A
T = 75ºC
A
10 0 20 30 40
V , INSTANTANEOUS REVERSE VOLTAGE (V)
Fig. 2 Typical Reverse Characteristics
R
T = 125ºC
A
T = 75ºC
A
T = 25ºC
A
100
10
1.0
0.1
0.01
1,000
I
, I
N
ST
ANT
A
NE
OU
S REV
E
RSE
CURRENT
(
µA)
R
1.0
10
100
0 15 10 25 30 35 20 40
C
,
T
O
T
AL
C
A
P
A
C
IT
AN
C
E (
p
F
)
T
V , DC REVERSE VOLTAGE (V)
Fig. 3 Total Capacitance vs. Reverse Voltage
R
5.0
T = 25 C
J
°
f = 1MHz
0
0
20
40
25 50 75 100 125 150
I,
A
V
E
R
A
G
E
R
E
C
T
IF
IE
D
C
U
R
R
EN
T
(mA
)
O
T , AMBIENT TEMPERATURE ( C)
Fig. 4 Forward Current Derating Curve
A
°
60
80
100
T = 125 C
J
°
Package Outline Dimensions
SOD323
Dim Min Max
A 0.25 0.35
B 1.20 1.40
C 2.30 2.70
H 1.60 1.80
J 0.00 0.10
K 1.0 1.1
L 0.20 0.40
M 0.10 0.15
α 0° 8°
All Dimensions in mm
K
L
M J
C
H
B A
