BAS40W /-04 /-05 /-06
Document number: DS30114 Rev. 15 - 2
2 of 4
February 2014
© Diodes Incorporated
BAS40W /-04 /-05 /-06
Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
Characteristic
Symbol
Value
Unit
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
V
RRM
V
RWM
V
R
40
V
RMS Reverse Voltage
V
R(RMS)
28
V
Forward Continuous Current (Note 6)
I
FM
200
mA
Non-Repetitive Peak Forward Surge Current
@ t = 1.0s
I
FSM
600
mA
Thermal Characteristics
Characteristic
Symbol
Value
Unit
Power Dissipation (Note 6)
P
D
200
mW
Thermal Resistance Junction to Ambient Air (Note 6)
R
θJA
625
°C/W
Operating Temperature Range
T
J
-55 to +125
°C
Storage Temperature Range
T
STG
-65 to +150
°C
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic
Symbol
Min
Max
Unit
Test Condition
Reverse Breakdown Voltage (Note 7)
V
(BR)R
40
⎯
V
I
R
= 10μA
Forward Voltage
V
F
⎯
380
1000
mV
mV
I
F
= 1.0mA, t
p
< 300μs
I
F
= 40mA, t
p
< 300μs
Leakage Current (Note 7)
I
R
⎯
200
nA
V
R
= 30V
Total Capacitance
C
T
⎯
5.0
pF
V
R
= 0, f = 1.0MHz
Reverse Recovery Time
t
rr
⎯
5.0
ns
I
F
= I
R
= 10mA,
I
rr
= 0.1 x I
R
, R
L
= 100Ω
Notes:
6. Device mounted on FR4 PC board with recommended pad layout, 7. Short duration pulse test used to minimize self-heating effect.
0.01
0.1
1
0.001
0.0001
0
1.0
0.6
0.8
0.4
0.2
I,
I
N
S
TAN
TAN
E
O
U
S
F
O
R
WA
R
D
C
U
R
R
EN
T
(A
)
F
V , INSTANTANEOUS FORWARD VOLTAGE (V)
Fig. 1 Typical Forward Characteristics
F
0.1
1
10
100
1,000
10,000
0
10
20
30
40
V , INSTANTANEOUS REVERSE VOLTAGE (V)
Fig. 2 Typical Reverse Characteristics
R
I
, IN
S
TAN
TANE
O
U
S
R
EVE
R
SE
C
U
R
R
EN
T
(n
A
)
R
