1N5711WS
SURFACE MOUNT SCHOTTKY BARRIER DIODE
Features
•
Low Forward Voltage Drop
•
Guard Ring Construction for Transient Protection
•
Fast Switching Speed
•
Low Capacitance
•
Surface Mount Package Ideally Suited for Automated Insertion
•
Lead, Halogen and Antimony Free, RoHS Compliant
"Green" Device (Notes 3 and 4)
Mechanical Data
•
Case: SOD-323
•
Case Material: Molded Plastic. UL Flammability Classification
Rating 94V-0
•
Moisture Sensitivity: Level 1 per J-STD-020D
•
Terminals: Solderable per MIL-STD-202, Method 208
•
Lead Free Plating (Matte Tin Finish annealed over Alloy 42
leadframe).
•
Polarity: Cathode Band
•
Marking Information: See Page 2
•
Ordering Information: See Page 2
•
Weight: 0.004 grams (approximate)
Top View
Maximum Ratings
@T
A
= 25°C unless otherwise specified
Characteristic
Symbol
Value
Unit
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
V
RRM
V
RWM
V
R
70
V
RMS Reverse Voltage
V
R(RMS)
49
V
Forward Continuous Current
I
FM
15
mA
Thermal Characteristics
Characteristic
Symbol
Value
Unit
Power Dissipation (Note 1)
P
D
150
mW
Thermal Resistance, Junction to Ambient Air (Note 1)
R
θJA
650
°C/W
Operating Temperature Range
T
J
-55 to +125
°C
Storage Temperature Range
T
STG
-55 to +150
°C
Electrical Characteristics
@T
A
= 25°C unless otherwise specified
Characteristic
Symbol
Min
Typ
Max
Unit
Test Conditions
Reverse Breakdown Voltage (Note 2)
V
(BR)R
70
⎯
⎯
V
I
R
= 10
μA
Reverse Leakage Current (Note 2)
I
R
⎯
⎯
200
nA
V
R
= 50V
Forward Voltage Drop
V
F
⎯
⎯
0.41
1.00
V
I
F
= 1.0mA
I
F
= 15mA
Total Capacitance
C
T
⎯
⎯
2.0
pF
V
R
= 0V, f = 1.0MHz
Reverse Recovery Time
t
rr
⎯
⎯
1.0
ns
I
F
= I
R
= 5.0mA,
I
rr
= 0.1 x I
R
, R
L
= 100
Ω
Notes:
1. Part mounted on FR-4 PC board with recommended pad layout, which can be found on our website at http://www.diodes.com/datasheets/ap02001.pdf.
2. Short duration pulse test used to minimize self-heating effect.
3. No purposefully added lead. Halogen and Antimony Free.
4. Product manufactured with Data Code V9 (week 33, 2008) and newer are built with Green Molding Compound. Product manufactured prior to Date Code
V9 are built with Non-Green Molding Compound and may contain Halogens or Sb
2
O
3
Fire Retardants.
1N5711WS
Document number: DS31033 Rev. 12 - 2
1 of 3
www.diodes.com
July 2008
